mod_slice Module Reference

Writes D-1 slice, can do so in various formats, depending on slice_type. More...

Functions/Subroutines
subroutine	write_slice
subroutine	put_slice (dir, xslice)
subroutine	select_slice (dir, xslice, writeonly, file_handle, normconv)
subroutine	fill_subnode (igrid, active, jgrid, dir, xslice, normconv)
subroutine	alloc_subnode (jgrid, dir, nwexpand)
subroutine	dealloc_subnode (jgrid)
subroutine	fill_subnode_info (igrid, jgrid, dir)
subroutine	get_igslice (dir, x, igslice)
double precision function	roundoff_minmax (val, minval, maxval)

Variables
integer, parameter	nslicemax =1000
	Maximum number of slices. More...
double precision, dimension(nslicemax)	slicecoord
	Slice coordinates, see Slice output. More...
integer	slicenext
	the file number of slices More...
integer	nslices
	Number of slices to output. More...
integer, dimension(nslicemax)	slicedir
	The slice direction for each slice. More...
character(len=std_len)	slice_type
	choose data type of slice: vtu, vtuCC, dat, or csv More...

Detailed Description

Writes D-1 slice, can do so in various formats, depending on slice_type.

Function/Subroutine Documentation

alloc_subnode()

subroutine mod_slice::alloc_subnode	(	integer, intent(in)	jgrid,
		integer, intent(in)	dir,
		integer, intent(in)	nwexpand
	)

Definition at line 992 of file mod_slice.t.

Here is the call graph for this function:

dealloc_subnode()

subroutine mod_slice::dealloc_subnode

(

integer, intent(in)

jgrid

)

Definition at line 1040 of file mod_slice.t.

Here is the call graph for this function:

fill_subnode()

subroutine mod_slice::fill_subnode	(	integer, intent(in)	igrid,
		logical, intent(in)	active,
		integer, intent(inout)	jgrid,
		integer, intent(in)	dir,
		double precision, intent(in)	xslice,
		double precision, dimension(0:nw+nwauxio), intent(out)	normconv
	)

Definition at line 854 of file mod_slice.t.

Here is the call graph for this function:

fill_subnode_info()

subroutine mod_slice::fill_subnode_info	(	integer, intent(in)	igrid,
		integer, intent(in)	jgrid,
		integer, intent(in)	dir
	)

Definition at line 1056 of file mod_slice.t.

Here is the call graph for this function:

get_igslice()

subroutine mod_slice::get_igslice	(	integer, intent(in)	dir,
		double precision, intent(in)	x,
		integer, dimension(nlevelshi), intent(out)	igslice
	)

Definition at line 1107 of file mod_slice.t.

Here is the call graph for this function:

put_slice()

subroutine mod_slice::put_slice	(	integer, intent(in)	dir,
		double precision, intent(in)	xslice
	)

Definition at line 43 of file mod_slice.t.

Here is the call graph for this function:

roundoff_minmax()

double precision function mod_slice::roundoff_minmax	(	double precision, intent(in)	val,
		double precision, intent(in)	minval,
		double precision, intent(in)	maxval
	)

Definition at line 1132 of file mod_slice.t.

select_slice()

subroutine mod_slice::select_slice	(	integer, intent(in)	dir,
		double precision, intent(in)	xslice,
		logical, intent(in)	writeonly,
		integer, intent(in)	file_handle,
		double precision, dimension(0:nw+nwauxio), intent(out)	normconv
	)

Definition at line 692 of file mod_slice.t.

Here is the call graph for this function:

write_slice()

subroutine mod_slice::write_slice

Definition at line 29 of file mod_slice.t.

Here is the call graph for this function:

Variable Documentation

nslicemax

integer, parameter mod_slice::nslicemax =1000

Maximum number of slices.

Definition at line 7 of file mod_slice.t.

nslices

integer mod_slice::nslices

Number of slices to output.

Definition at line 16 of file mod_slice.t.

slice_type

character(len=std_len) mod_slice::slice_type

choose data type of slice: vtu, vtuCC, dat, or csv

Definition at line 22 of file mod_slice.t.

slicecoord

double precision, dimension(nslicemax) mod_slice::slicecoord

Slice coordinates, see Slice output.

Definition at line 10 of file mod_slice.t.

slicedir

integer, dimension(nslicemax) mod_slice::slicedir

The slice direction for each slice.

Definition at line 19 of file mod_slice.t.

slicenext

integer mod_slice::slicenext

the file number of slices

Definition at line 13 of file mod_slice.t.
